型号Model

DN

PN

LW

d1

i

L

L1

B

H

hi

h2

h3

SW

S

KHB3K-G1/8

4

315

6

G1/8

10

69

37

28

44.5

13

34

8

9

35

KHB3K-G1/4

6

315

6

G1/4

14

69

37

28

44.5

13

34

8

9

35

KHB3K-G3/8

10

315

10

G3/8

14

72

42

32

52.5

17

40

8

9

36

KHB3K-G1/2

13

315

13

G1/2

16

83

48

35

52.5

17

40

8

9

40

KHB3K-G1/2

16

315

15

G1/2

16

83

47

38

63.5

19

43

11

9

42

KHB3K-G3/4

20

315

20

G3/4

18

95

60

48

75

24

54

12

12

49

KHB3K-G1

25

315

25

G1

20.5

113

65

55

82

28.5

61

12

12

56.5

KHB3K-G174

25/32

315

25

G174

22

120

65

60

82

28.5

61

12

14

60

KHB3K-G1V4

32

315

30

G174

22

110

84

75

104.5

37.5

84

14

17

55

KHB3K-G172

40

315

38

G172

24

130

91

85

115.5

42.5

95

14

17

65

KHB3K-G2

50

315

48

G2

26

140

100

105

133

52.5

112.5

14

17

70
